SPECIFICATION :
Frame
Canyon Ultimate CFR Disc
Pro-level build of our latest 5th-generation Ultimate frame.
Classic road race design, engineered for the perfect balance of comfort, toughness, stiffness, lightness, and aerodynamics.
Material: world-class carbon fibre (CFR layup)
Axle dimension: 12x142 mm
Material: Carbon (CFR)
Fork
Canyon FK0108 CF Disc
Carbon fork optimised for lightness, stiffness, and strength.
Material: carbon
Steerer: 1 1/4”
Axle dimension: 12 x 100 mm
Brake mount: flat mount
Axle dimension: 12x100 mm
Material: Carbon (CF)
Rear Derailleur
Shimano Dura-Ace Di2 R9250,12-speed
Pro-level wireless derailleur providing Shimano’s fastest-ever shifting.
Front Derailleur
Shimano Dura-Ace Di2 R9250
Semi-wireless derailleur with world-class performance. 45% faster shifting. 33% smaller frontal area.
Superlight: only 99 g
Attachment type: braze-on
Cassette
Shimano Dura-Ace R9200, 12-speed, 11-30
The latest generation of superlight Shimano cassettes.
Gear range: 11-30 T
Crank
Shimano Dura-Ace Di2 R9200 Powermeter
Pro-level crankset with optimal balance of stiffness, strength, weight, and performance. With integrated dual-sided power meter – waterproof, with rechargeable li-ion battery.
Number of chainrings: 2
Bottom bracket
Shimano Pressfit BB92
Pressfit BB86 standard, compatible with 24 mm axles, featuring Hollowtech 2 technology.
Weight: 54 g
Chain
Shimano CN-M9100 12s
The latest generation of Shimano chains. With SIL-TEC treatment for extended durability.
Shift-/ Brake Lever
Shimano Dura-Ace Di2 R9270, 12-speed
Number of pistons: 2
Shift-/ Brake Lever
Shimano Dura-Ace Di2 R9270, 12-speed
Number of pistons: 2
Brake Rotor
Shimano XTR RT-MT900
Premium XTR rotor with superb stopping power for the most aggressive riding. With Ice Freeza tech for superior heat management.
Mount: centrelock
Superlight: 88 g
Brake Rotor
Shimano XTR RT-MT900
Premium XTR rotor with superb stopping power for the most aggressive riding, with Ice Freeza tech for superior heat management.
Superlight: 108 g
Disc Mount: Centerlock
Size: 160 mm
Wheel
DT Swiss PRC 1100 Dicut Mon Chasseral
DT Swiss’ lightest disc climbing wheelset, hand-made in Europe.
Tubeless-ready
Hub type: 180 with Ratchet EXP 36
Rim depth: 24 mm
Bearings: SINC ceramic
Wheelset weight: 1266 g
Wheel
DT Swiss PRC1100 Dicut Mon Chasseral SH11
DT Swiss’ lightest disc climbing wheelset, hand-made in Europe. Tubeless-ready.
Hub type: 180 with Ratchet EXP 36
Rim depth: 24 mm
Bearings: SINC ceramic
Wheelset weight: 1266 g
Tyre
Schwalbe Pro One TT Evo 25mm
Casing: MicroSkin
Compound: OneStar
Technology: Tubeless Easy
Tyre
Schwalbe Pro One TT, 28mmm
Pure race tyre: speed, minimum rolling resistance, minimum weight.
Carcass: Super Race
Compound: Addix Race
Thru Axle
DT Swiss through axle without lever
Aluminium construction.
Thread pitch: 1.75 mm
Axle dimension: 12x100 mm
Thru Axle
DT Swiss through axle with lever
Aluminium construction.
Thread pitch: 1.75 mm
Axle dimension: 12x142 mm
Cockpit
Canyon CP0018 Aerocockpit
Aero design, reinforced carbon walls for added stiffness and improved durability.
Easy width adjustment: +/-20 mm
Cut-free height adjustment: 15 mm
Weight: 440 g
Material: Carbon (CF)
Handlebar Tape
Canyon Ergospeed Gel
Bar tape with EVA foam and elastomer gel mix for optimal comfort.
Color: black
Saddle
Selle Italia SLR C59
Superlight 61 g saddle with full-carbon construction and SuperFlow cutout for extra comfort.
Maximum approved rider weight: 90 kg
Gender: Male
Seatpost
Canyon SP0064
Superlight custom carbon seatpost with aerodynamic D-shape profile.
Setback: 0 mm
Weight: 70 g
Clamp diameter: 27,2 mm
Material: Carbon (CF)
Light
Reflector Set
Pedals
None included
Manuals and Accessories
Canyon Bag
Storage box for tools and replacement parts.
Manuals and Accessories
Canyon starter box
All you need to get riding: Quick Start Guide, manual, torque wrench incl. bit set, assembly paste.
Manuals and Accessories
Quickstart Guide Ultimate CF
